Offsetting Roof Gables From Same Roof Revit

See image 1 2nd roof set properties base height offset to same as cutoff height use pick line and pick edges of roof at cutoff height and lock.

Offsetting roof gables from same roof revit.

There are other cheat ways but all use 2 roofs and join geometry but this is easiest to explain. Draw geometry similar to below and select all but 3 top edges as shown. Hip roofs are more stable than gable roofs. It will join the roofs together getting rid of the line.

A gable roof is placed at the top of a hip roof for more space and enhanced aesthetic appeal. The first method works only for gable or shed roofs but not hip roofs. Set desired line to not define slope gable join geometry all done. Whether you want a double gable roof with 6 pyramid shaped dormers or a simple gambrel roof the basics remain the same.

1st roof set cutoff height. The second works for all roof types. That would include the small overhangs at the gable. The inward slope of all four sides is what makes it more sturdy and durable.

But to answer your question about getting rid of the line just use the join command. There are 2 ways to extend the roof parallel to a ridge. Those are easily modeled into the same roof as the main one. Personally i try to do as much with 1 roof as i can.

Modifying revit roof slopes to change the roof from a gable roof to hip roof go into the sketch options select all boundary lines and turn on the defines slope parameter note as a default your roof will have a slope of 30 degrees on all boundaries and form a hip roof unless you change the slope designation in the sketch mode per. Revit roof slope can seem complicated at first glance but by learning a few critical features you can create any roof shape you desire. The sides are all equal length and come together at the top to form the ridge. Repeat steps 2 and 3 to generate the gable roof.

A hip roof has slopes on all four sides. In this video i show how to add the following roof types in revit hip roof gable roof shed roof saltbox roof gambrel roof gullwing roof half hip roof mansard rood follow me on.
